E-mail: zhulin@zozen.com Chat Line Send Inquiry35 tons boiler is a common boiler tonnage, can be used for self-owned power plant power generation, can also be used for heating small thermal companies, can also be used for large-scale industrial steam supply, is widely used. At present, 35 tons of coal-fired boilers are still the most widely used. Although boilers advocate the promotion of large-scale gas-fired boilers, but because of the high operating costs, most of China is unable to achieve 35 tons of gas-fired boilers to replace 35 tons of coal-fired boilers. Moreover, 35 tons of biomass boilers have the advantage of catching up with the others, because many regions have made great efforts to subsidize, coupled with biomass and coal at the same time suitable for circulating fluidized bed boilers and other high-efficiency boiler type, so that its economic benefit is far higher than the significance of natural gas boilers to the boiler users in China. The following is a list of the specifications, models and technical parameters of all types and 35 tons of various fuels fired boilers in ZOZEN Boiler plant:
1) Boiler type SZS35-3.82/412-Q:35 tons SZS condensing gas boiler (superheated steam), rated evaporation capacity 35 t/h, rated steam pressure 3.82 mpa, steam temperature 412, feed water temperature 104, design thermal efficiency minimum 92.5%, flue gas temperature 140, bulk shipment.
2) boiler type SZS35-1.25/350-Y.Q:35 ton double-drum gas boiler (superheated steam), rated evaporation capacity 35 t/h, rated steam pressure 1.25 mpa, steam temperature 350, feed water temperature 104, design thermal efficiency minimum 94%, flue gas temperature 145, bulk shipment.
3) boiler type SZS35-1.25-Y.Q:35 tons SZS condensing boiler (saturated steam), rated evaporation capacity 35 t/h, rated steam pressure 1.25 mpa, steam temperature 194, feed water temperature 104, natural gas consumption 2625 Nm3/h, bulk shipment factory;
1) Boiler type DHL35-1.25-AII:35 ton DHL corner tube chain-fired boiler, rated evaporation capacity 35 t/h, rated steam pressure 1.25 mpa, steam temperature 194, feed water temperature 105, designed fuel class II bituminous coal, boiler bulk shipment.
2) boiler type DHL35-1.6-A II:35 ton DHL corner tube chain boiler, rated evaporation capacity 35 t/h, rated steam pressure 1.6 mpa, steam temperature 204, feed water temperature 105, designed fuel class II bituminous coal, boiler bulk shipment factory.
3) boiler type DHL35-2.5-A II:35 ton corner tube coal-fired boiler, rated evaporation capacity 35 t/h, rated steam pressure 2.5 mpa, steam temperature 226, feed water temperature 105, designed fuel for class II bituminous coal, boiler bulk shipment factory.
1) 35 ton corner tube biomass saturated steam boiler: rated evaporation capacity 35 t/h, rated steam pressure 1.25 mpa, steam temperature 194, feed water temperature 105, designed fuel for the formation of biomass particles, boiler bulk shipment.
2) 35 tons biomass fluidized bed steam boiler, rated evaporation capacity 35 t/h, rated steam pressure 1.25 mpa, steam temperature 230, feed water temperature 105, designed fuel for molding biomass particles, smoke stem, distiller's grains, leather waste liquor, etc., boiler bulk shipment factory.
The model parameters of the 35-ton waste heat boiler are quite special. For other fuel boilers, the application parameters of customers in many industries are the same. But different from waste heat boilers, in addition to evaporation and steam pressure and other parameters, there is a special need for flue gas related parameters, and is shown in the type of waste heat boiler. However, the flue gas parameters of HRSG in different industries are very different. Therefore, the type parameters of this type of 40 ton boiler can not be recommended in practice, and the customers need to explain the requirements to us according to their own actual situation.
